How F1 deals with its toughest braking challenge

The Canadian Grand Prix is the most demanding circuits on the Formula 1 calendar for brakes.

How F1 deals with its toughest braking challenge

Featuring four braking zones defined as 'hard' by Brembo – Turns 6, 8, 10 and 13, and further three braking events – two medium and one light – while almost a quarter of the lap time is spent slowing the car.

Although mechanically the operation of F1 brakes remains broadly the same, the systems have evolved significantly over the past 20 years to deal with the challenge of a circuit like Montreal.

Front brake disc width (28mm)
Front brake disc width (28mm)

Photo by: Giorgio Piola

In 1998, the FIA introduced rules restricting the brake system to calipers with a maximum of six pistons and no more than two pads.

The maximum brake disc diameter was set at 278mm, and maximum thickness at 28mm.

For last season, because of the higher speeds, the widening of the cars and, in particular, the wider tyres that increased mechanical grip under the new regulations, the permissible disc thickness was increased to 32mm.

Major progress has been made in brake disc material and Brembo, which supplies multiple F1 teams including Ferrari, has been among those at the forefront of development.

In 2013, Brembo introduced the new CER material to replace the old CCR type, which offered gains in terms of performance and wear and reduced maximum wear of 4-5mm on the hardest tracks to around 1mm.

Brembo brake discs evolution 2005-2015
Brembo brake discs evolution 2005-2015

Photo by: Giorgio Piola

The ventilation has also improved, with the number of holes increasing over the years, from a 100-hole disc to 1200 and then to the current maximum 1400 for the 32mm discs.


Brake pedal assembly and brake disc and caliper arrangement
Brake pedal assembly and brake disc and caliper arrangement

Photo by: Giorgio Piola

With the introduction of the current Energy Recovery Systems technology in 2014, F1 adopted brake-by-wire technology for the rear brakes thanks to the demands of harvesting energy from them.

F1 cars have separate brake cylinders for the conventional front axle brakes and the brake-by-wire system at the rear to allow the brake bias to be adjusted.



Brake by wire system
Brake by wire system

Photo by: Giorgio Piola

This Brembo diagram explains how the brake-by-wire system works.

The brake pedal [1] controls the braking of the front and rear axle via two separate brake cylinders, with the driver able to adjust the bias between the front and rear end.

Under braking, the system works at the front as in the past with the pump pressurising the fluid acting on the pistons, the pads and the discs to slow the car.

The rear brakes uses electronics to manage the system, which includes a 'compliance chamber' [6] that gives the driver more feel.

The system is controlled by an electronic control unit [7] that slows the motor generator [7] and, through an actuator [8], creates pressure in the rear brakes [9].

The braking effort at the rear is through a combination of the pressure on the brakes and the deceleration effect of the MGU-K being charged by the heat energy being recovered.

The extent of the latter is dictated by how much energy is being recovered at any given time, with F1 regulations stipulating a maximum yield of 2MJ per lap.

At the front end, the traditional six-pot calipers remain [10], but at the rear the discs are smaller by up to 12mm and some have four pistons.

5 pistons Brembo brakes caliper
5 pistons Brembo brakes caliper

Photo by: Giorgio Piola

In 2014, Mercedes, McLaren, Sauber and Red Bull all cut back to four pistons on the rear brakes and 260mm rather than 278mm diameter discs, as well as a reduction in width to 26mm.

This was because of the decreased demand on the brakes thanks to the braking caused by harvesting energy, as fewer pistons reduces the amount of pressure that can be applied to the pads.

Brake-by-wire system, depicts what happens when ERS not working (defaults to manual brake system)
Brake-by-wire system, depicts what happens when ERS not working (defaults to manual brake system)

Photo by: Giorgio Piola

In that year's Canadian Grand Prix Mercedes was running first and second when both cars lost use of MGU-K and, as a result, had to use the rear brakes conventionally without the braking effect of harvesting or the management by the brake by wire system.

This eventually cost Nico Rosberg the lead to Daniel Ricciardo, while team-mate Lewis Hamilton retired shortly after jumping ahead of his team-mate at the first pitstop with rear brake failure thanks to the extra loading created by using the brakes conventionally.

Mercedes W05 and W06 rear brakes comparison
Mercedes W05 and W06 rear brakes comparison

Photo by: Giorgio Piola

As a result of those problems, Mercedes subsequently reverted to a six-piston caliper, although McLaren, Red Bull and Sauber continue to use four.

In the recent Monaco Grand Prix, when Ricciardo lost the use of the MGU-K, he also had to adapt to the loss of braking at the rear being created by harvesting energy.

"The rear brakes got really hot, so I went six or seven per cent forwards with the brake balance," said Ricciardo after his victory.

"That's a lot. Maybe we go one or two per cent change during the race, so we had to go a long way forwards and I had to lift a lot before braking to save the brakes and put less energy through them."

McLaren MP4-8 1993 drive-by-wire detail overview
McLaren MP4-8 1993 drive-by-wire detail overview

Photo by: Giorgio Piola

The introduction of brake-by-wire technology in F1 came 22 years after McLaren introduced the first fly-by-wire throttle technology in 1992.

At the Brazilian Grand Prix early in the season, the McLaren MP4/7 ran with electronically managed hydraulic actuators instead of the traditional throttle cable.

The pressure the driver felt in the throttle pedal was created by an external spring, marked in yellow.

Canada's brake demands

Montreal's Circuit Gilles Villeneuve puts very different demands on the brakes to the previous race at Monaco.

In Monaco, the challenge is to cool the brake caliper because there are multiple, regular braking events but not from high speed.

Mercedes F1 W08 brake duct at Canadian GP
Mercedes F1 W08 brake duct at Canadian GP

Photo by: Giorgio Piola

Ferrari SF70H brake duct, captioned
Ferrari SF70H brake duct, captioned

Photo by: Giorgio Piola

The lack of high speed running also means teams must run the maximum size of brake duct to keep the brakes cooled.

In Canada, cooling the disc and managing the wear is the most important thing.

The above images show the Mercedes and Ferrari brake cooling configuration from Canada last year, with the maximum number of ventilation holes.

Many drivers have suffered braking problems at the circuit, for example Heinz-Harald Frentzen crashing out late in the 1999 race after suffering a failure.

Based on data released last year by Brembo, the maximum deceleration in Montreal is 4.8g, with the braking zone for the hairpin particular demanding.

Of the seven braking points in Montreal, the most critical being is braking zone into the final right/left chicane that exits by the 'wall of champions'.

Cars hit the brakes at around 322km/h and brake for 1.6s to slow to around 148km/h.

This takes only 49 metres, with 4.7g deceleration and a force on the brake pedal of 161kg.

The Turn 8 right/left chicane requires cars to slow from around 297km/h in 47 metres and 1.62s, at 4.8g deceleration with 160kg force on the pedal.

The hairpin at Turn 10 is the best overtaking opportunity, with a 63 metre braking zone to go from 292km/h to around 68km.h in 2.44s.

Each Formula 1 team uses around 10 sets of brake calipers per season, as well as 140-240 brake discs and 280-480 pads.
